Sistem analiza Century 2000 pentru holtere

Sistem analiza Century 2000 pentru holtere

Detalii produs

Categoria: Cardiologie
Firma: Sales Promotion Agency

Overview

Holter analysis software featuring a suite of prospective and retrospective analysis tools for fast and accurate processing of Holter recordings.

The Century 2000 represents the entry level of prospective superimposition-scanning. Building on the powerful analysis and editing tools that represent the foundation of the Century family, the C2000 adds high speed prospective superimposition of the ECG data during the analysis. This allows the user to easily identify rhythms and ECG variations for later review and editing. In addition, an advanced trends module provides even greater flexibility for review or editing and includes an sophisticated search utility to quickly locate arrhythmias.

Specifications

Analysis Tools and Capabilities

  • 2 channel arrhythmia analysis, either user-selectable or automatic
  • 3 channel ST segment analysis
  • QT analysis on any single channel
  • Time-domain Heart Rate Variability
  • Supports sampling rates from 128 to 1024

 Holter Recorder Compatibility

  • Datrix VX3 Digital Holter recorders
  • Braemar DL and DXP series Digital Holter Recorders
  • ELA SpiderView™ Digital Holter Recorder
  • Cassette Recorders (system option)

 Software Features

  • Automated arrhythmia analysis including retrospective editing tools
  • Page-mode display with color-coded beat highlighting
  • Template Editing with the ability to superimpose within any individual templates
  • RR Interval histograms and scatter plots
  • Validation Display for rapid identification of significant events
  • On-screen display of all analysis tables with editing capabilities
  • Point-and-Click Beat Editing

 Final Report Options*

  • Cover Page (Paragraph or Tabular)
  • General Table
  • Supraventricular Ectopy Table
  • Ventricular Ectopy Table
  • Bradycardia Table
  • Pacemaker Activity Table
  • ST and Heart Rate Trend
  • Ectopy Histograms
  • Heart Rate Variability
  • Strip List Summary
  • Diagnostic Strips
  • Patient Event Strips
  • Significant Event Strips
  • Full Disclosure
*Reports can be customized to include any or all of thesections listed above. The cover page can be customizedwith your logo and paragraph text that is specific to yourfacility or to individual referring physicians.

Century 2000 Configurations

The system is available as software-only (includes flash card reader or recorder interface cable) or can be furnished as a complete solution including computer hardware and printer.
